Gravimetric dosing devices
Tschritter dosing devices for exact and homogeneous mixing results 24/7
EFFICIENT. SOLID. RELIABLE.
-
- Up to 50 kg/h
- Max. 4 components
- Drum dosing devices
- Compact design
- Installation directly on (injection molding) machines
- Easy cleaning
- Integrated conveying
- Automatic adaptation to bulk density
- Emptying function
- Manual operation
-
Gravimetric batch dosing device for plastic granulate, additives and regrinds. Up to 4 components are successively dosed into the weighing hopper via dosing sliders and/or drum dosing devices. The device has an integrated conveying system.
-
Design: Stainless steel Dosing: Dosing slider / Drum dosing device Batch size: max. 500g Material storage: D150 – 2,5 Liter
Weighing bin: 2 Liter Mixing container: 3 Liter Control system: Touch Connection: 380-480 VAC / 50-60 Hz Compressed air: 6 atm -
- Mounting frame
- Recipe management and charge tracking with additional control display
-
- Up to 300 kg/h
- Max. 4 components
- Easy cleaning
- Integrated conveying
- Automatic adaptation to bulk density
- Emptying function
- including mounting frame
- Manual operation
-
Gravimetric batch dosing device for plastic granulate, additives and regrinds. Up to 4 components are successively dosed into the weighing hopper via dosing sliders and/or drum dosing devices. The device has an integrated conveying system.
-
Design: Stainless steel Dosing: Dosing slider / Drum dosing device Batch size: max. 5kg Material storage: D210 – 4,5 Liter Weighing bin:: 16 Liter Mixing container:: 20 Liter Cotrol system: LCD 8-rows Connection: 380-480 VAC / 50-60 Hz Compressed air: 6 atm -
- Add. components on request
- Drum dosing device
- Mobile version available
- Control system with touch panel
- Recipe management and charge tracking with additional control display
-
- Complete machine supply in one system
- Including side channel blower 4,3 kW
- Including prefilter VF30
- Up to 300 kg/h
- Max. 4 components
- Easy cleaning
- Integrated conveying
- Automatic adaptation to bulk density
- Emptying function
- Manual operation
-
MOBILE, gravimetric batch dosing device for plastic granulate, additives and regrinds. Up to 4 components are successively dosed into the weighing hopper via dosing sliders and/or drum dosing devices. The device has an integrated conveying system.
-
Design: Stainless steel Dosing: Dosing slider / Drum dosing device Batch size: max. 5kg Material storage: D210 – 4,5 Liter Weighing bin:: 16 Liter Mixing container:: 20 Liter Cotrol system: LCD 8-rows Connection: 380-480 VAC / 50-60 Hz Compressed air: 6 atm -
- Add. components on request
- Drum dosing device
- Control system with touch panel
- Recipe management and charge tracking with additional control display
-
- Up to 700 kg/h
- Max. 5 components
- Easy cleaning
- Integrated conveying
- Automatic adaptation to bulk density
- Emptying function
- including mounting frame
- Manual operation
-
Gravimetric batch dosing device for plastic granulate, additives and regrinds. Up to 5 components are successively dosed into the weighing hopper via dosing sliders. The device has an integrated conveying system.
-
Design: Stainless steel Dosing: Dosing slider Batch size: max. 10kg Material storage:: D210 – 4,5 Liter
D300 – 20 Liter
D370 – 16 LiterWeighing bin:: 35 Liter Mixing container:: 60 Liter Control system: LCD 8-rows Connection: 380-480 VAC / 50-60 Hz Compressed air: 6 atm -
- Additional components on request
- Mounting frame with catwalk
- Recipe management and charge tracking with additional control display
-
- Up to 1200 kg/h
- Max. 4 components
- Easy cleaning
- Integrated conveying
- Automatic adaptation to bulk density
- Emptying function
- including mounting frame
- Manual operation
-
Gravimetric batch dosing device for plastic granulate, additives and regrinds. Up to 4 components are successively dosed into the weighing hopper via dosing sliders. The device has an integrated conveying system.
-
Design: Stainless steel Dosing: Dosing slider Batch size: max. 15kg Material storage:: D370 – 16 Liter
D480 – 65 Liter
D630 – 135 LiterWeighing bin:: 75 Liter Mixing container:: 90 Liter Control system: LCD 8-rows Connection: 380-480 VAC / 50-60 Hz Compressed air: 6 atm -
- Additional components on request
- Recipe management and charge tracking with additional control display
